Mini Action Jack Plate (50hp Max) Bolt Or Clamp 6" Adjustable, 100-801000 BMS-100-801000

$2,572.00
RRP $3,187.00
SAVE $615.00 (19%)
In Stock (2 ) - Dispatches in 2 days


Calculate Shipping

Bobs Machine Shop Mini Action Jack Plate (50hp Max) Bolt or Clamp, 6" Adjustable, 100-801000

Bob’s Machine Shop has just launched a new line of jack plates for smaller boats with lower-hp engines. The lightweight Mini Jacs feature a smaller footprint and, depending on the model, will handle engines up to 50 hp.

High-performance boaters use jack plates for more speed, better fuel economy and improved boat handling. In recent years, jacks have also become popular with fishermen and pleasure boaters who operate in shallow water. Bob’s Machine Shop’s jack plates use hi-tech bearings that will not absorb water.  They also feature automobile-type grease fittings – a unique feature among jack plates.

Mini Action Jacs come in two models:  The standard version weighs 40 pounds and has same dimensions as BMS’s regular jack plates.  It fits the standard BIA bolt pattern and provides 6″ of hydraulic lift.  The other is a narrow version only for clamp on motors.

***Note : This unit can be used for either full BIA bolt pattern Bolt on motors, OR any clamp on motors.  Most clamp on will want to use the Narrow unit, but if you think you might upgrade in future, or have a motor with a wide bracket, this is a perfect choice!***

Product Features:

  • Lifetime warranty on structure
  • Automotive grease nipples for easy lubrication
  • Tension rods
  • Made in USA, in our own factory in Tampa, Florida
  • Includes Jack plate, wiring harness, relays, rocker style switch
  • Limited Lifetime Structure Warranty against manufacturing defects
  • 6″ of hydraulic lift
  • Pump integrated into jack plate  (1 year warranty on pump)
  • 40 pounds/18 kilos
  • 6″/15cm set back.

(A-BMS-100-801000)

SKU A-BMS-100-801000
Model # 100-801000
Brand Bobs Machine
Shipping Weight 18.0000kg
