Reversible 5 Degree Transom Wedge Pair BMS-319-2000000

Reversible 5 Degree Transom Wedge Pair

Bob’s Reversible wedges for either positive or negative trim.  Machined billet units with Bob’s Machine Shop engraved into them.  Look great, and will never crack.

Sold as a pair (for 1 engine)

Offering 5 degrees of either negative or positive trim.  Most cases they are used to provide negative trim, for when your bow will not come down enough due to the angle of the motor (transom is built without enough of a negative angle).  This is a quick, cheap and effective fix!

3″ is width

14″ total length

1.5" Maximum wedge thickness (5 Degrees)

Will need bolts that are 1.5″ longer for ‘thicker side of wedge’, and 0.25 longer for ‘thin side of wedge’.

Stainless steel Wedge washers available – add on item (washers come as a set of 4) To go behind the motor so that nut lies flat.
