Blue Sea Systems 285 Series 25 Amp Circuit Breaker BS-7080
25 Amp Panel Mount
$118.00
RRP $159.90
SAVE $41.90 (26%)
In Stock (10
)
- Dispatches in 2
days
Provides circuit protection for 25-150amp loads when switching and circuit protection are both required.
• Visible yellow reset lever shows open condition
• Trip-free design cannot be held closed after trip
• Drop in replacement for 185 Series Circuit Breakers
• 3,000A AIC for medium battery banks
Specifications
• Interrupting Capacity 3,000A @ 48V DC†
• Voltage Max. Operating 48V DC
• Temperature Min. Operating -40°C
• Temperature Max. Operating 85°C
• Type Thermal
• Class Type III – Switchable/Manual Reset – Trip Free
• Terminal Stud M6 (accepts 1/4″ Ring Terminal)
• Terminal Stud Torque 50 in-lb (7.9 Nm)
• Mounting Hole Accepts 1/4″ screw (M6)
| Code Surface Mount | Bulk Code Surface Mount | Code Panel Mount | Amps | |||
|---|---|---|---|---|---|---|
| BS-7180 | BS-7080 | 25 | ||||
| BS-7181 | BS-7081 | 30 | ||||
| BS-7182 | BS-7182B | BS-7082 | 40 | |||
| BS-7183 | BS-7183B | BS-7083 | 50 | |||
| BS-7184 | BS-7184B | BS-7084 | 60 | |||
| BS-7185 | BS-7085 | 70 | ||||
| BS-7186 | BS-7186B | BS-7086 | 80 | |||
| BS-7187 | BS-7187B | BS-7087 | 100 | |||
| BS-7188 | BS-7088 | 120 | ||||
| BS-7189 | BS-7089 | 150 |
(B-P-BS-7080)
| SKU | B-P-BS-7080 |
| Brand | Blue Sea Systems |
