DF-4406-4 - Marine Engine Mounts EM-DF-4406-4

Dual Flex Marine Mount - DF-4400 Series - DF-4406-4

Suitable for

Perkins - T6-3544M

The Dual Flex DF-4400 Series of heavy duty mountings is designed principally for diesel engines in the 816 - 998kg range.

Sugested maximum engine weight per mount with 4 mounting feet: Up to 249.5kg per mount.

DF-4406-4

Length -170mm
Width - 95mm
Overall height - 144mm
Minimum mounting height - 81mm
Mounting bolt centres - 127mm
Stud size - 1"
Weight rating per mount - 249.5kg
Weight rating per set - 998kg

Base casting features heavy duty aluminum alloy construction, with lip incorporated in the top of the casting to resist the upward pull of the engine - coated black to resist corrosion.

Durable oil and fuel resistant elastomer element.

Fail safe design - bottom pad prevents excessive impact.

Easy installation with full 1” threaded stud for vertical height and slotted casting for horizontal adjustment.

Mounts come complete - furnished with three nuts: leveling, locking and secondary lock.

Aluminum base cast with 1/2” slotted mounting holes for 1/2” bolts or lag screws on 5” centers.

All steel parts are zinc trivalent plated for corrosion resistance.
